| Place of Origin: | CHINA |
|---|---|
| Brand Name: | XK |
| Certification: | ISO9001 / GB / IEC |
| Model Number: | HY10W, HY5W |
| Minimum Order Quantity: | 12 Pieces |
| Price: | Negotiation |
| Packaging Details: | carton |
| Standard: | IEC60099 | Application: | Electric Power System |
|---|---|---|---|
| Product Name: | Surge Lightning Arrester | Product Keywords: | Lightning Arrester |
| Selling Units: | Single Item | Single Package Size : | 43X30X35 Cm |
| Package Type: | EXPORTING PACKAGE | ||
| High Light: | line surge arrester,mov surge arrester |
||
Founded in 2011 , Zhejiang Xinkou Electric Power Equipment Co., Ltd. is located in Yiliu City, the "Electric Capital of China" on the coast of the East China Sea. It has the most beautiful wind and convenient transportation.
Zhejiang Xinkou Power Equipment Co., Ltd. is a high-tech enterprise integrating the development, design, manufacture, sales and import of high and low voltage electrical appliances.
The company's main products are: indoor and outdoor high-voltage vacuum circuit breakers, sulfur hexafluoride circuit breakers, load switches, indoor and outdoor high-voltage disconnectors, drop-out fuses, lightning arresters, overvoltage protectors, voltage / current transformers, transformer Cars, etc. The product performance fully complies with GB, IEC, ANSI and other standards and the technical requirements of the company's products.
Zhejiang Xinkou Electric Power Equipment Co., Ltd. adheres to the principle of "Continuous Progress, Integrity and Pragmatism, Unity and Innovation", and adheres to the "Quality First" policy in order to better serve customers and serve various power systems!
We sincerely welcome people from all walks of life to visit us for friendly cooperation and achieve a win-win situation!
| Type |
Rated voltage (kV) |
MCOV (kV) |
Residual voltage (KV) |
2000ms square wave impulse current withstand |
4/1OMS high current impulse (kV) |
||
|
Steep current impulse |
switching current impulse |
8/20 ms Lightning current impulse |
|||||
| HY10W-3 | 3 | 2.55 | 9.5 | 7.7 | 9 | 100 | 100 |
| HY10W-6 | 6 | 5.1 | 19.5 | 15.4 | 18 | 100 | 100 |
| HY10W-9 | 9 | 7.65 | 28.5 | 23. 1 | 27 | 100 | 100 |
| HY10W-10 | 10 | 8.4 | 36 | 30 | 23 | 250 | 150 |
| HY10W-11 | 11 | 9.4 | 40 | 33 | 30 | 250 | 150 |
| HY10W-12 | 12 | 10.2 | 38.0 | 30.8 | 36 | 200 | 100 |
| HY10W-15 | 15 | 12.7 | 47.5 | 38.5 | 45 | 200 | 100 |
| HY10W-18 | 18 | 15.3 | 57.0 | 46.2 | 54 | 200 | 100 |
| HY10W-21 | 21 | 17.0 | 66.5 | 53.9 | 63 | 200 | 100 |
| HY10W-24 | 24 | 19.2 | 76.0 | 61.6 | 72 | 200 | 100 |
| HY10W-27 | 27 | 21.9 | 85.5 | 69.3 | 81 | 200 | 100 |
| HY10W-30 | 30 | 24.2 | 95.0 | 76.5 | 90 | 200 | 100 |
| HY10W-33 | 33 | 26.8 | 104.5 | 84.7 | 99 | 400 | 100 |
| HY10W - 36 | 36 | 29 | 114.0 | 92.4 | 108 | 400 | 100 |
| HY10W-42 | 42 | 34.1 | 132.3 | 100. 1 | 126 | 400 | 100 |
| HY10W-48 | 48 | 39 | 152.0 | 126.0 | 150 | 400 | 100 |
| HY10W-54 | 54 | 43 | 171.0 | 139.0 | 162 | 600 | 100 |
| HY10W-60 | 60 | 48 | 208.0 | 160.0 | 180 | 600 | 100 |
| HY10W-66 | 66 | 52.8 | 230.0 | 172.0 | 198 | 600 | 100 |
Q1. Can we have our logo or company name to be printed on your products or the package?
Yes,you can.Logo and company name can be printed on our products by silk screen printing.You can send us the artwork by email in JPEG or TIFF format.
Q2. What is lead time?
Usually 3-15 working days, On-Time delivery
Q3. Why us?
All products comply with the requirements of GB national standards, IC, ANSI and other international standards, and the requirements of company's technology standards.
Q4. How do you make our business long-term and good relationship?
1. Our high quality and competitive price are the most important factors to maintain long-term and good relation -ship with our customers.
2. Good service is our basic principle for every customers.
Q5. Can I have a visit to your factory before the order?
Sure,welcome to visit our factory.
