| Place of Origin: | Zhejiang, China |
|---|---|
| Brand Name: | XK |
| Certification: | ISO9001 / GB / IEC |
| Model Number: | PD-36 |
| Minimum Order Quantity: | 1 Piece/Pieces |
| Price: | Negotiation |
| Packaging Details: | EXPORTING PACKAGE |
| Supply Ability: | 100 Piece/Pieces per Month |
| Product Keywords: | Dropout Fuse Cut Outs | Standard: | GB1208-2006 |
|---|---|---|---|
| Usage: | High Voltage | Breaking Capacity: | High |
| Safety Standards: | IEC | Rated Voltage: | 36 |
| Mechanical Life: | 10000 | Rated Current: | 100A/200A |
| Port: | NINGBO | ||
| High Light: | 100 amp cut out fuse,fuse cut out 20 kv |
||
Type Test :
Dielectric test
Mechanical test
Breaking test
Temp. rise test
Dry power frequency voltage withstand test
Wet power frequency voltage withstand test
Lightning impulse voltage withstand test
Temperature rise test
Physical operation test
Product Range : 15 KV, 24 KV, 36 KV
| Type | PD - 36/100 | PD - 36/200 |
| Rated Voltage(kV) | 36 | 36 |
| Rated current(A) | 100 | 200 |
| Breaking current(A) | 10000 | 12,000 |
| Impulse voltage(kV) | 170 | 170 |
| Power frequency wihstand voltage(kV) | 70 | 70 |
| Creepage distance(mm) | 720 | 720 |
| Weight(kg) | 5 | 5 |
| Dimensions(CM) | 61X34X11.5 | 61X34X11.5 |
Q1. Can we have our logo or company name to be printed on your products or the package?
Yes,you can.Logo and company name can be printed on our products by silk screen printing.You can send us the artwork by email in JPEG or TIFF format.
Q2. What is lead time?
Usually 3-15 working days, On-Time delivery
Q3. Why us?
All products comply with the requirements of GB national standards, IC, ANSI and other international standards, and the requirements of company's technology standards.
Q4. How do you make our business long-term and good relationship?
1. Our high quality and competitive price are the most important factors to maintain long-term and good relation -ship with our customers.
2. Good service is our basic principle for every customers.
Q5. Can I have a visit to your factory before the order?
Sure,welcome to visit our factory.
